Store home > KVM Switches and Extenders > KVM Switches > DVI KVM Switches > DCX Digital CATx KVM Matrix Switch
DCX3000: KVM Matrix Switch, 30 endpoints
Photo may vary from actual product
DCX Digital CATx KVM Matrix Switch
DCX3000: KVM Matrix Switch, 30 endpoints
DCX3000-DVR: Remote User Station, (1) DVI-D + (2) USB
DCX3000-DVR: Remote User Station, (1) DVI-D + (2) USB
DCX3000-DVT: Server Access Module, (1) DVI + (1) USB
DCX3000-DPT: Server Access Module, (1) DisplayPort + (1) USB
DCX1000: KVM Matrix Switch, 10 endpoints
DCX-VGA: Server Access Module, (1) VGA + (1) USB
DCX-VGA: Server Access Module, (1) VGA + (1) USB
DCX-VGA: Server Access Module, (1) VGA + (1) USB
DCX1000-2X4-DVI: Smart Switching Bundles, 2 users x 4 DVI-CPUs


DCX Digital CATx KVM Matrix Switch


Digital high performance KVM Matrix Switching with convenient CATx-connections


  • Digital KVM Matrix Switching for up to 30 endpoints.
  • Intuitive switching via on-screen menus using auto refreshed preview thumbnails.
  • Zero compression, zero latency with pixel perfect video.
  • Single-, Dual or Multi-Head video operation up to 1920x1200@60Hz.
  • Add computers with DVI, DisplayPort, or VGA and USB interfaces using Zero U SAMs.
  • Supports USB HID and Windows 8+ compatible Touchscreens plus stereo audio.
  • Works with user consoles with DVI- or HDMI Displays and USB keyboard/mouse/touchscreen.
  • Convenient server and user connections over shielded CAT6 or higher cables.
  • Extend computers up to 10m, and user console up to 50m from the switch.
  • Features a multi-view thumbnail OSD, so that all systems can be seen on the screen at the same time.
  • Secure configuration via web browser with four operation modes: video only, shared, exclusive and private access.
  • Reliable 24/7 availability with redundant power.
  • Cost-effective KVM switching solution for small and medium sized applications with high performance graphic demands.

Share |
  Product       Code   Unit price
KVM Matrix Switch

10 endpoints
  DCX Digital CATx KVM Matrix Switch
DCX Digital CATx KVM Matrix Switch
  DCX1000   Sign in to view prices

30 endpoints
  DCX Digital CATx KVM Matrix Switch
DCX Digital CATx KVM Matrix Switch
  DCX3000   Sign in to view prices
Remote User Station

(1) DVI-D + (2) USB
  DCX Digital CATx KVM Matrix Switch
DCX Digital CATx KVM Matrix Switch
  DCX3000-DVR   Sign in to view prices
Server Access Module

(1) DisplayPort + (1) USB
  DCX Digital CATx KVM Matrix Switch
DCX Digital CATx KVM Matrix Switch
  DCX3000-DPT   Sign in to view prices

(1) DVI + (1) USB
  DCX Digital CATx KVM Matrix Switch
DCX Digital CATx KVM Matrix Switch
  DCX3000-DVT   Sign in to view prices

(1) VGA + (1) USB
  DCX Digital CATx KVM Matrix Switch
DCX Digital CATx KVM Matrix Switch
  DCX-VGA   Sign in to view prices
Smart Switching Bundles

2 users x 4 DVI-CPUs
  DCX Digital CATx KVM Matrix Switch
DCX Digital CATx KVM Matrix Switch
  DCX1000-2X4-DVI   Sign in to view prices
Order one Server Access Module for each computer connection and one Remote User Station for each user console connected to the switch.
Or start smart with our scalable bundle for 2 users and 4 DVI computers offering you a nice price advantage.

NOTE: Product must be connected with shielded CAT6/6A or CAT7 cables only.

Accessories

  Product     Code   Unit price

  CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH - Black, 1m
CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH
  C6PC60S-BK-01M   Sign in to view prices
  CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH - Black, 2m
CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH
  C6PC60S-BK-02M   Sign in to view prices
  CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH - Black, 3m
CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH
  C6PC60S-BK-03M   Sign in to view prices
  CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH - Black, 5m
CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH
  C6PC60S-BK-05M   Sign in to view prices
  CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH - Black, 7.5m
CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH
  C6PC60S-BK-07M5   Sign in to view prices
  CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH - Black, 10m
CAT6 Sc/FTP GigaTrue® 3 Lockable Patch Cable, LSZH
  C6PC60S-BK-10M   Sign in to view prices
  Agility Extender Kit - Extender Kit, (1) Single-Link DVI
Agility Extender Kit
  ACR1000A-R2   Sign in to view prices
  Agility Dual DL Transmitter - Transmitter, (2) Single-Link or (1) Dual-Link DVI
Agility Dual DL Transmitter
  ACR1002A-T   Sign in to view prices
  Agility Dual DL Receiver - Receiver, (2) Single-Link or (1) Dual-Link DVI
Agility Dual DL Receiver
  ACR1002A-R   Sign in to view prices
  Freedom II KVM Switch
Freedom II KVM Switch
  KV0004A-R2   Sign in to view prices
Power Supply
  Spare/Redundant Power Supply
Spare/Redundant Power Supply
  PS655   Sign in to view prices
  Spare Power Supply, Receiver
Spare Power Supply, Receiver
  PS656   Sign in to view prices
Rack/Mount Kit
  19"-Rackmount Kit for 2x DCX-Receivers or Extender units
19"-Rackmount Kit for 2x DCX-Receivers or Extender units
  DCX3000-DVR-RMK   Sign in to view prices
